| MODEL |
HG-50
|
HG-80
|
| Overall (W x D x H) |
19.7" x 27.2" x 35.0"
(45.5 cm x 69.1 cm x 89.0 cm)
|
19.7" x 27.2" x 40.6"
(45.5 cm x 69.1 cm x 103.0 cm)
|
Chamber
(Diameter x Height) |
50 liters
14.3" x 19.0" (36.4 cm x 48.2 cm)
|
76 liters
14.3" x 28.7" (36.4 cm x 73.0 cm)
|
| Temperature Range |
105°C to 135°C
|
| Sterilization Timer |
1 to 300 minutes
|
| Agar Warming Range |
After sterilization, agar can be maintained from 45°C to 60°C (programmable) for up to 24 hours to prevent coagulation
|
| Delayed Auto-Start |
Program autoclave to start 1 to 99 hours later
|
| Cooling Fan |
Switch to turn fan on or off
|
| Air Removal Timer |
Programmable, 3 to 9 minutes after temperature has reached 97°C
|
| Steam Venting |
Selectable from: No venting and three other venting rates
|
| Temperature for Release of Lid Interlock |
Programmable, 60°C to 97°C for greater safety and flexibility
|
| Sterilization Program Cycles |
1) Liquid cycle, 2) Agar (liquid with warming) cycle, and 3) Solid cycle
|
| Additional Cycles for Agar Dissolution |
Cycle for dissolving and keeping agar warm (no sterilization)
|
| Agar Dissolution Protocol |
Initially at 60°C-100°C for 1-60 min., then at 45°C-60°C for up to 24 hrs.
|
| Safety Features |
Circuit breaker with GFCI, low-water power cut-off, over-temp power cutoff, over-pressure power cut-off, safety valve, sensor for improper lid closing
|
| Steam Condenser |
15-liter water tank
|
| Drain Water Bottle |
2 liters
|
| Power Requirements |
120V or 220V, 50/60 Hz, single phase
|
220V, 50/60 Hz, single phase
|
| Power Consumption |
2.0kW, optional 3.0kW for 220V only
|
3.8 kW
|
| Shipping Weight |
180 lb (82 kg)
|
255 lb (116 kg)
|
